The ADATA XPG SX8200 Pro has been present in the SSD market since 2018. Thanks to its price to performance ratio, it one of the most recommended m.2 NVMe. It is said to be a great alternative to Samsung’s 970 Evo thanks to its price to performance ratio.

The ADATA XPG SX8200 Pro is priced at ₱8640 at PCHub (as of this writing) and performance peaks up to 3.5/GBs Read and 3GB/s Write with Random 4K numbers reaching up to 390,000 IOPS.

ProductXPG SX8200 Pro 256GBXPG SX8200 Pro 512GBXPG SX8200 Pro 1TBXPG SX8200 Pro 2TB
Pricing (PCHub)₱3180₱4850₱8640₱15,950
Form FactorM.2 2280 D5M.2 2280 D5M.2 2280 D5M.2 2280 D5
Interface/ProtocolPCIe 3.0 x4 / NVMe 1.3PCIe 3.0 x4 / NVMe 1.3PCIe 3.0 x4 / NVMe 1.3PCIe 3.0 x4 / NVMe 1.3
ControllerSMI SM2262ENSMI SM2262ENSMI SM2262ENSMI SM2262EN
DRAMNANYA DDR3NANYA DDR3NANYA DDR3NANYA DDR3
MemoryMicron 64-Later TLCMicron 64-Later TLCMicron 64-Later TLCMicron 64-Later TLC
Sequential Read3,500 MB/s3,500 MB/s3,500 MB/s3,500 MB/s
Sequential Write 1,200 MB/s2,300 MB/s3,000 MB/s3,000 MB/s
Random Read220,000 IOPS390,000 IOPS390,000 IOPS390,000 IOPS
Random Write290,000 IOPS380,000 IOPS 380,000 IOPS 380,000 IOPS
EncryptionN/AN/AN/AN/A
Endurance160 TBW 320 TBW 640 TBW 1280TB
Part Number ASX8200PNP-256GT-C ASX8200PNP-512GT-C ASX8200PNP-1TT-C ASX8200PNP-2TT-C
Warranty5-Years 5-Years 5-Years 5-Years

Packed with Micron’s 64L 3D TLC, the ADATA SX8200 Pro provides an SMI SM22626En controller giving better performance and more efficiency. The controller also brings support for NVMe 1.3 with end-to-end data protection and a RAID Engine for data integrity.

Product TBWDWPDWarranty
Adata XPG SX8200 Pro 1TB6400.355
Intel SSD 660p 1TB 2000.11 5
Corsair Force MP510 960GB17000.935
Samsung 970 PRO 1TB 12000.665
Adata XPG GAMMIX S11/SX8200 960GB 6400.355
Samsung 860/970 EVO 1TB 6000.335
WD Black 1TB 6000.335
WD Blue 3D 1TB 4000.373
Crucial MX500 1TB 3600.205

The SX8200 Pro comes with a 5-year warranty along with an endurance rating that goes up to 640TBW (terabytes written) for the 1TB model. This is more than enough for the average gamer or PC enthusiast. The SMI also improved power consumption with the new SM22626EN controller. The SX8200 Pro supports multiple NVMe low power states and has an active rating of 0.33W and a slumber rating of 0.14W.

Going over to the design of the ADATA XPG SX8200 Pro 1TB drive, we see the Silicon Motion SM12262EN with IMFT 64-Layer TLC NAND Flash and NANYA DDR3 DRAM chip.

ADATA XPG SX8200 Pro 1TB JamOnline
ADATA XPG SX8200 Pro 1TB Box Contents

Once you flip it over, we are greeted with the double-sided M.2 2280 model. This particular model easily fits in most desktop builds but might not be applicable for notebook laptops that support thinner single-sided drives.



Going through the retail box, ADATA provides an optional matte black-and-red heat spreader to add more aesthetics but would not be necessary should your motherboard have its heatsink provided.

SOFTWARE

ADATA SSD ToolBox
ADATA SSD ToolBox

The ADATA SSD Toolbox comes free from to download from their website should you need it. The application allows for firmware updates, secured drive erasures, force TRIM service, run diagnostics, and more.

ADATA XPG SX8200 PRO M.2 2280 PCIe Gen3x4 SSD TEST

PCMARK8 Storage Test

Starting with the PCMark 8’s Storage test, this synthetic benchmark replicates everyday disk access like photo editing and web browsing. The variations on this test regarding PCIe drives are quite small.

PCMark8 Storage Test JamOnline.Ph
PCMark8 Storage Test

Crystal DiskMark

With our Crystal DiskMark, this replicates best-case, straight-line transfers of large files. This benchmark supports Native Command Queueing (NCQ) with a queue depth of 32 and represents the highest score of five runs.

CrystalDiskMark7 Benchmark ADATA SX8200 Pro
CrystalDiskMark7 Benchmark Real World ADATA SX8200 Pro
CrystalDiskMark7 Benchmark Peak ADATA SX8200 Pro
CrystalDiskMark7 Benchmark Peak ADATA SX8200 Pro

The ADATA SX8200 Pro 1TB drive maxed out at 3164.03MB/s read and 2707.14MB/s write in the standard sequential write test that was done at Q8T1. Random 4K Q1T1 performance is at 27.94 MB/s read and 149.66 MB/s write.

ATTO Disk Benchmark

ATTO being one of the longest drive benchmarks used until today is still relevant in the SSD market. ATTO gives an idea of transfer across a specific volume length. This test was done with default runs.

ATTO DISK BENCHMARK JamOnline
ATTO DISK BENCHMARK ADATA XPG SX8200 PRO

This benchmark shows the ADATA SX8200 Pro 1TB SSD speeds reaching up to 2.74 GB/s read and 1.15 GB/s write at Qeue Depth of 4. This is way below the rated read/write speeds of 3500/3000 MB/s.

AS SSD Benchmark

AS SSD benchmark gives a variety of results. There are now three tests that are found within the tool.

AS SSD - IOPS ADATA XPG SX8200 PRo JamOnline
AS SSD – IOPS ADATA XPG SX8200 PRO
AS SSD - Read and Write ADATA XPG SX8200 PRo JamOnline
AS SSD – Read and Write ADATA XPG SX8200 Pro

The ADATA SX8200 Pro gives an overall score of 4,134 points with sequential read speeds of  2845.77 MB/s read and 2602.17 MB/s write. While the 4K random results are at 50.77MB/s read and 137.43 MB/s write.

AS SSD - Compression ADATA XPG SX8200 PRo JamOnline
AS SSD – Compression ADATA XPG SX8200 PRO

For this chart, a straight line would be ideal as you wouldn’t want any compression performance loss.

FINAL FANTASY XIV LOADING TIME

On this part of the review, we use the Final Fantasy XIV – Stormblood Benchmark which represents 5 Scenes and total loading times. This would give a representation of how fast each scene would load when booting up games and transitioning levels.

FFXIV Loading Times ADATA SX8200 Pro JamOnline
FFXIV Loading Times ADATA SX8200 Pro

Final Thoughts & Conclusions

It is great to see that the ADATA XPG SX8200 Pro is equipped with the SMI SM2262EN controller. Our performance results give outstanding performance results. The key takeaways here are that the performance, availability of various capacities, 5-year warranty, and value. At ₱8640 for the 1TB version, it is a great price for a high capacity SSD that is reliable.
